Description
Hawk HD and Hawk HD Deluxe Floor Machines
165 RPM - 13", 15”, 17” and
20”
Stripping, Scrubbing, Carpet Care
Hawk Standard and HD Models
- F13-01 HP1513-HD 13 INCH FLOOR MACHINE, 1-1/2 HP AC 115V 60 Hz
- F15-03 HP1515-HD 15 INCH FLOOR MACHINE, 1-1/2 HP AC 115V 60 Hz
- F17-01 HP1517-HD 17 INCH FLOOR MACHINE, 1-1/2 HP AC 115V 60 Hz
- F20-01 HP1520-HD 20 INCH FLOOR MACHINE, 1-1/2 HP AC 115V 60 Hz
- F13-01-DX HP1513-HD 13 INCH FLOOR MACHINE DELUXE, 1-1/2 HP AC
115V 60 Hz (INCLUDES - TANK, PREMIUM PAD DRIVER, SPLASHGUARD, & CHROME MOTOR) - F15-03-DX HP1515-HD 15 INCH FLOOR MACHINE DELUXE, 1-1/2 HP AC
115V 60 Hz (INCLUDES - TANK, PREMIUM PAD DRIVER, SPLASHGUARD, & CHROME MOTOR) - F17-01-DX HP1517-HD 17 INCH FLOOR MACHINE DELUXE, 1-1/2 HP AC
115V 60 Hz (INCLUDES - TANK, PREMIUM PAD DRIVER, SPLASHGUARD, & CHROME MOTOR) - F20-01-DX HP1520-HD 20 INCH FLOOR MACHINE DELUXE, 1-1/2 HP AC
115V 60 Hz (INCLUDES - TANK, PREMIUM PAD DRIVER, SPLASHGUARD, & CHROME MOTOR)
Realize maximum
power with the twin capacitor, AC motor and Hawk's ruggedly reliable floor
machine design. Machine operators appreciate the solid performance of an
extremely well-built floor machine that delivers reliability on every job.
Power
• 1.5 HP, 66 frame, dual capacitor AC motor
• 115V, 60 Hz power, (230V optional)
• 50 ft. (14-3) STO industrial power cord with molded plug
• 1.5 HP, 66 frame, dual capacitor AC motor
• 115V, 60 Hz power, (230V optional)
• 50 ft. (14-3) STO industrial power cord with molded plug
Drive System
• Triple-planetary HD 10:1 helical-cut commercial gears drive pads and
• Triple-planetary HD 10:1 helical-cut commercial gears drive pads and
brushes at 175
RPM
Engineered Design
• All steel construction with welded, powder-coated frame
• One piece chrome, heavy-duty steel handle with vinyl grips
• Variable position positive handle lock
• 13", 15”, 17” and 20” steel brush covers with full wraparound bumper
• Dual steel operating triggers
• Negative pressure on/off switch
• Thumb-operated safety switch
• 1” x 5” non-marking ball bearing wheels
• The addition of weights can stress equipment components. Adding
• All steel construction with welded, powder-coated frame
• One piece chrome, heavy-duty steel handle with vinyl grips
• Variable position positive handle lock
• 13", 15”, 17” and 20” steel brush covers with full wraparound bumper
• Dual steel operating triggers
• Negative pressure on/off switch
• Thumb-operated safety switch
• 1” x 5” non-marking ball bearing wheels
• The addition of weights can stress equipment components. Adding
weights to non
XHD models is not recommended.
Safety Features
• Quiet 60 dB operation. Meets GS42 standard.
• UL/CUL listed
• Quiet 60 dB operation. Meets GS42 standard.
• UL/CUL listed
Part Numbers
